Body & Chassis
Windshield	Optional
Hitch Front	No
Hitch Rear	No
Body Options	Standard: Front and Rear 1/2 Door

Suspension & Wheels
Suspension Front	High-Clearance Dual A-Arm with Stabilizer Bar, 2.5 in FOX Podium Shocks with Live Valve (Electronically Controlled Damping)
Suspension Front Travel	20 in
Suspension Rear	Trailing Arm & High-Clearance Radius Rods with Stabilizer Bar , 2.5 in FOX Podium Shocks with Live Valve (Electronically Controlled Damping)
Suspension Rear Travel	22 in
Steering	High Assist Electronic Power Steering with Quick Turn Rack
Tires Front Size	30 x 10 x 14
Tires Rear Size	30 x 10 x 14
Wheels Front Material	Cast Aluminum
Tires Front Material	Maxxis Carnivore II
Tires Rear Material	Maxxis Carnivore II
Wheels Rear Material	Cast Aluminum
Brakes Front	Hydraulic Disc with Dual-Bore XL Front and Dual-Bore Rear Calipers
Brakes Rear	Hydraulic Disc with Dual-Bore XL Front and Dual-Bore Rear Calipers
Parking Brake	Park In-Transmission
Num Wheel	4

Safety Features
Seat Belts	Yes
ROPS	Yes
Seat Belt Type	Retractable Click-6 Harnesses
Safety Mirrors	Optional
Headlights	Yes
Headlights Type	Signature White LED, Low/High
Horn	Optional
Bumpers	Yes
Safety Options	Standard: Low/High & Red LED Tail / Brake Lights; Front, Rear, and Interior Accent Lighting

Transmission & Driveline
Drive Unit/Differential	Isolated Xtreme Performance True On-Demand AWD/2WD
Engine-braking	No
Gear Selection	P/R/N/L/H
Transmission	Automatic PVT

Dimensions
Length	155 in
Width	64 in
Height	73.6 in
Wheelbase	125 in
Dry Weight	2066 lb
Ground Clearance	14.5 in

Performance
Fuel Tank Capacity	13 gal
Payload Capacity	900 lb
Cargo Box/Deck Capacity	300 lb
Cargo Box/Deck Dimensions	27.7 x 52.8 x 19.5 in
